| Active Display Area | 2436mm(H)×1370mm(V) |
| Aspect Ratio | 16:9 |
| Visual Angle | Horizontal178/Vertical178 |
| Panel | CSOT, BOE, etc., A Level |
| Brightness | 400cd/m2 |
| Contract Ratio | 4000:1 |
| Resolution Ratio | 3840*2160 |
| Color Components | 8 Bit+ FRC,1.07G Colors |
| Refresh rate | 60HZ |
| Response Time | 8ms |
| Power Consumption | 450W |
| Standby power consumption | ≦0.5W |
| Glass | 3mm thickness standard AG tempered glass |
| Touch screen spec | IR 40-point touch screen, Interpolation Resolution: 32768 x32768,Touch Accuracy:90% Central Area:±2mm,Touch Height:3mm,Response Time:4~11ms,Output Mode:HID Standard,Theory Clicks:Infinite,Minimum Touch Object:2 points ≥ 3mm / multi points ≥ 5mm,Connect Type:Full Speed,Voltage:DC 5V±5%,Power Consumption:≤1W |
| Speaker | 8Ω 10W*2pc |
| Power Supply | Input:AC110-240V-50/60Hz |
| Color of Shell | Dark grey |
| Life of Panel | 60000Hours |
| Tablet and Smart phone wireless screen sharing (miracast by software) | Support, cost extra |
| Dimension of Machine | L2590xH1590xW141mm |
| Carton box packing | 2660*300*1660mm, G.W.: 148KG |
| Photo formats | JPG, JPEG, BMP, PNG etc. |
| Audio formats | MPEG1/2 layer I/II,AC-3(To be customized),AAC-Lc,WMA… |
| Video formats | MPEG2-4,H.264,H.265,TS, Realmedia, etc. |
| OSD Language | English, Chinese, Arabic etc. |
| Working Temperature/ Hulmidity | -10℃-50℃ / 10%RH~90%RH |
| Storage Temperature/ Hulmidity | -20℃-60℃ / 10%RH~90%RH |
| Accessory | Wall mount*1,Power Cord*1,Remote Control*1,Touch Pen*2,Qualified Certificate label*1,Warranty Card*1 |
| Front port | USB 3.0*2 , HDMI in*1, Touch *1, Type C*1 |
| Other function |
| Smooth writing | Smooth writing experience, touch delay <8MS |
| Touch menu | Touch on the screen through gestures to achieve menu, signal source switch, sound, brightness and other functions control |
| Intelligent signal switching | Connect and input the signal, the device will automatically identify and switch to the corresponding video signal source channe |
| Gesture wipe function | Wipe text and patterns on the screen with gestures |
| Two-way control function | Touch the screen to control the computer, convenient and fast |
| Wireless screen transfer function | No need to plug in the cable, you can project the content on the computer to the screen (optional) |
| Zoom in, zoom out, drag | Using multi-touch technology, picture zoom in/out arbitrarily, and move the picture freely |
| Android Mainboard Configuration |
| CPU | T982-N0DN, Cortex A55*4, Mali-G52 MP2 (2EE) |
| RAM | DDR3 4G |
| Memory | 32G |
| OS | Android 13.0, support Google play |
| Bluetooth | 5.0 |
| Wifi | 2.4G and 5.0G |
| Side view port | USB3.0*1,USB2.0*1,HDMI IN*2,TOUCH*1,LINE OUT*1,RJ45*1 |
| Bottom view port | MIC*1,RS232*1,OPTICAL*1,VGA IN*1,AUDIO IN*1 |
| OPS Configuration |
| CPU | i3-4th |
| Memory | DDR3 4G |
| SSD | 128G |
| OS | Windows10 Pro |
| Wifi | M.2 PCIe 2230 |
| JAE Connector | Type-c SUPER IO 1 JAETX25 |
| Input Port | RJ45 in*1, USB3.0*2, USB2.0*4, Mic in*1 |
| Output Port | HDMI out*1, VGA out*1, Line out*1, Audio out*1 |
